Shunt Reactor Market Report 2024 Key Trend, Future Opportunities Forecast To 2032

3 min read


The Shunt Reactor market is expected to develop at a compound annual growth rate (CAGR) of 5.00% from USD 2.42 billion in 2023 to USD 3.57 billion by 2032.

The Shunt Reactor market size was estimated at USD 2.3 billion in 2022.

Shunt reactors play a crucial role in power transmission systems, contributing to the stability and efficiency of the electrical grid. They are essential components that help manage reactive power and maintain voltage levels within acceptable limits.

Shunt reactors, focusing on Fixed Shunt Reactors, Variable Shunt Reactors, Air Core Shunt Reactors, and the intricacies of Shunt Reactor Switching.

Shunt Reactor Companies

·       Nissin Electric

·       ABB

·       Mitsubishi

·       Crompton

·       Fuji Electric

·       Toshiba

·       Zaporozhtransformator

  1. Fixed Shunt Reactors:

Fixed Shunt Reactors are designed to provide a constant amount of reactive power compensation to the power system. They are permanently connected to the network and are crucial for maintaining voltage levels by absorbing excess reactive power when it is in surplus and releasing it when the demand for reactive power is high. Fixed Shunt Reactors are particularly effective in preventing voltage instability and improving the power factor of the system.

  1. Variable Shunt Reactors:

Unlike their fixed counterparts, Variable Shunt Reactors offer the flexibility of adjusting the level of reactive power compensation. This dynamic feature allows system operators to adapt to changing network conditions and optimize reactive power support. Variable Shunt Reactors are equipped with a tap changer mechanism, enabling operators to modify the reactor’s inductance and, consequently, the amount of reactive power injected into the system.

  1. Shunt Reactors in Power Transmission Systems:

Shunt reactors are an integral part of power transmission systems, especially in high-voltage networks. They help mitigate voltage fluctuations and enhance the overall reliability of the grid. By counteracting the capacitive nature of long transmission lines, shunt reactors improve the power factor and stabilize the voltage profile, ensuring a steady and efficient flow of electricity over extended distances.

  1. Air Core Shunt Reactors:

Traditional shunt reactors use iron or other magnetic materials in their core construction. However, Air Core Shunt Reactors take a different approach by utilizing air as the core medium. These reactors are known for their low losses and are often employed in applications where minimizing energy dissipation is crucial. Air Core Shunt Reactors find applications in high-voltage direct current (HVDC) transmission systems and other scenarios where efficiency is paramount.

  1. Shunt Reactor Switching:

Switching operations involving shunt reactors require careful consideration due to the potential transient overvoltages and inrush currents. Proper switching procedures are essential to prevent equipment damage and ensure the seamless integration of shunt reactors into the power system. Advanced control and protection systems are employed to manage the switching process effectively, mitigating the associated challenges and maintaining system stability.


Shunt reactors are indispensable components in power transmission systems, offering solutions to manage reactive power and voltage stability. Whether in the form of Fixed Shunt Reactors providing constant support or Variable Shunt Reactors offering adaptability, these devices contribute significantly to the efficiency and reliability of electrical grids. The emergence of Air Core Shunt Reactors and the intricacies of Shunt Reactor Switching highlight the continuous advancements in power system technology aimed at achieving a more stable and resilient energy infrastructure.
